Dolmar EV-3213 - ASSEMBLY; Assembling the handle bar; Assembling the grass catcher; Cord strain relief

11
WARNING:
•This machine produces an
electromagnetic eld during
operation.Itisrecommendedthat
persons with medical implants
shouldconsulttheirdoctorsand
implant manufacturers before
using this machine. Otherwise
the electromagnetic eld may
affect medical implants and it
mayresultinseriousinjury.
ASSEMBLY
CAUTION:
•Alwaysbesurethatthemachine
is switched off and unplugged
beforecarryingoutanyworkon
thetool.
Assembling the handle bar (Fig. 2, 3, 4)
1)Insert the lower handle bar (6) into the support (7).
Alignthescrewholesonthem,andthenfastenthem
byascrew.Performthissteponbothsides.
2)Placethemiddlehandlebar(5)ontothelowerhandle
bar(6).Alignthescrewholes of those handles,and
then fasten them withthe knob(4), spacer, and the
bolt.Performthissteponbothsides.
3)Placetheupperhandlebar(3)ontothemiddlehandle
bar (5). Fasten each side of the upper bar with the
knob(4),spacer,andthebolt.
4)Fastenthecordwiththeclips(12)ontothehandlebar.
Assembling the grass catcher
CAUTION:
•Do not operate the machine
withoutgrasscatcher.Otherwise
ejectedobjectmaycauseinjury.
•For rear discharge appliances
withexposedrearrollers,when
usedwithoutacatcher,fulleye
protectionshallbeworn.
NOTE:
• The performance of the machine reduces when the
grasscatcherisfull.Emptythegrasscatcheronregular
basisbeforeitbecomescompletelyfull.
Installingthegrasscatcher
Pullupthedeectorguard(10)andholdit.Inserthooks
onthegrasscatcherintothegroovesonthemachine.
Removingthegrasscatcher
Pullupthedeectorguard(10)andholdit.Removethe
grasscatcherby releasing thehooks from thegrooves
onthemachine.
Cord strain relief (Fig. 5)
Thecordstrainrelief(2)helpstopreventthecordfrom
entanglingintothebladeorwheel.
Makeasmallloopattheendofthemainscord,andpass
itthroughtheopeningofthecordstrainrelief,andthen
hangitonthehook.
Always takethe position of the cordinto consideration
duringoperation. Startyouroperation fromthenearest
point to the power supply to prevent the cord from
accidentallycut.Itisrecommendedkeepingthecordover
yourshoulderduringtheoperation.
