Dolmar HT-2145 D - Handle Components; Gearbox and Drive Train; Shear Blade Mechanism; Control Lever and Cable

Page
Pos.
HT-2145 D
HT-2162 E
Part No. Notes Description Specifications
4 1 2 374 008 345 GRIP
4 2 1 381 611 400 HANDLE(LEFT)
4 3 2 381 005 028 BOLT
4 4 1 374 136 103 HANDLE FITTING
4 5 1 381 611 600 BUSH
4 6 1 381 500 210 CORD BINDER
4 7 1 374 136 141 DRUM COMPLETE
4 8 3 381 406 016 BOLT M6X16
4 9 1 381 500 010 GREASE NIPPLE M6
4 10 2 381 405 000 U-NUT M5
4 11 1 382 610 000 UPPER CASE
4 12 3 381 005 000 NUT M5
4 13 2 381 406 001 BALL BEARING UU 6001
4 14 1 381 202 800 SNAP RING
4 15 1 381 610 400 PINION GEAR
4 16 2 381 300 608 BALL BEARING ZZ 608
4 17 1 381 610 300 CRANK GEAR ASSY
4 18 2 383 105 016 SCREW M5-16
4 19 2 381 611 300 ROD
4 20 1 381 302 600 SNAP RING
4 21 1 381 610 200 CASE PACKING
4 22 1 381 811 200 STANDARD EQUIPMENT BLADE COVER
4 23 6 381 405 012 BOLT M5X12
4 24 1 381 610 100 LOWER CASE
4 25 1 381 611 200 FELT
4 26 1 382 106 000 WAVE WASHER
4 27 1 381 000 400 SCREW
4 28 4 381 000 200 SCREW L=19
4 29 5 374 008 250 BLADE SLIDING WASHER
4 30 1 381 850 580 STANDARD EQUIPMENT LOWER BLADE
4 31 1 381 850 560 STANDARD EQUIPMENT UPPER BLADE
4 32 1 381 610 500 HOLDING PLATE
4 33 1 374 605 998 CLAMP
4 34 5 381 406 000 U-NUT M6
4 35 1 381 706 010 WASHER M6
4 36 1 374 136 190 HANDLE (RIGHT)
4 37 1 381 224 600 LABEL
4 39 1 381 506 018 BOLT M6X18
4 142 1 381 307 001 TUBE
4 143 1 367 373 000 SWITCH ASS'Y
4 144 1 367 115 000 SWITCH STAY
4 145 1 381 145 004 LABEL
4 146 1 367 050 250 SCREW M5X25 (W/SW)
4 147 1 367 004 990 CONTROL CABLE
4 148 1 367 500 400 CONTROL LEVER
HT-2162 E
