Dolmar PB-7601.4 - Technical Data

TECHNICAL DATA
Model
PB-7600.4
PB-7601.4
Mass (without blower pipe) (kg) 10.2㧔22.4lbs㧕
Dimension (without blower pipe L x W x H) (mm) 350 × 430 × 495㧔13.716.919.5 in㧕
Max. engine speed (min
-1
) 7,200
Idling speed (min
-1
) 2,800
Engine displacement (mL) 75.6㧔4.61 cu,in㧕
Fuel Automobile gasoline
Fuel tank capacity (L) 1.9㧔64.2 fl.oz㧕
Engine oil
SAE 10W-30 oil of API Classification, Class SF or higher (4-stroke
engine for automobile)
Engine oil volume (L) 0.22㧔7.4 fl.oz㧕
Carburetor (Diaphragm-carburetor) WALBRO WYK
Ignition system Solid state ignition
Spark plug NGK CMR6A
Electrode gap (mm) 0.7 - 0.8㧔0.028 – 0.031 in㧕
Noise Level㧔50Feet per ANSI B175-2-2000㧕  (dB(A)) 74
Notes:
1. Use the oil and spark plug specified by DOLMAR.
2. This specification is subject to change without prior notice.
6
