Dolomite ALPHA BASIC - Adjusting the Brake Handle (Alpha Advanced); Braking

Dolomite®AlphaBasic/Dolomite®AlphaAdvanced
1.LoosenthetwoknobsA.
2.Adjustthetwoarmsupportcupstoappropriatewidth/angle.
3.TightenthetwoknobsA.
3.5Adjustingthebrakehandle(Alpha
Advanced)
Thebrakehandlecanbeadditionallyadjustedforoptionalhand
locationandfunctiondirection.
B
A
C
1.LoosenthescrewAwiththesuppliedAllenkey.
2.AdjustthefasteningdeviceBinheightandsidewaystothe
desiredposition.
3.Rotatethebrakebymeansoftheballjointtothedesired
position.
4.RetightenthescrewA.
Thebrakecanbesetatagreateranglebytwistingthepipe
Cinconnectionwiththedepthadjustment,→3.4Adjusting
thearmsupport,page8
.
3.6Braking
Brakingduringusage
AlphaBasicAlphaAdvance
1.Pullbothbrakehandles(AlphaBasic)orbrakelevers(Alpha
Advance)towardsyourbody.
Applyingtheparkingbrakes
IMPORTANT!
–Inparkingposition,alwaysensurethatbothbrakes
areapplied.
AlphaBasicAlphaAdvance
101576161-C
