MXH94x / MXH95x Transparent Adapter User’s Guide – Dolphin Interconnect Solutions Page 7
• Transparent Cable port configurations, up to
o One x16
o Two x8
o Four x4 (Supported using MXH946 and MXH956 only)
• Pre-loaded firmware configurations, DIP switch selectable. Please reference the adapter card firmware release note for
details.
• Microchip / Microsemi Switchtec PM40036B PFX PCI Express Gen4 chipset. (PM40052B used in Rev A and B cads)
• 100 nanosecond cut-through latency port to port.
• Support for optical patch cables up to 100 meters.
• Low profile, Half-length - PCI Express Electromechanical Specification, Rev 4.0.
• Dimensions 167.65mm (6.600 inches) x 68.90 mm (2.731 inches)
• Host clock isolation. Automatic support for host running CFC or SSC mode.
• VAUX powered board management controllers for flexible configuration and cable management.
• Flash recovery option. PFX Multi configuration support.
• Operating Temperature: 0°C - 55°C (32°F - 131°F), Air Flow: 700 LFM
• Relative Humidity: 5% - 95% (non- condensing)
• Regulatory
o RoHS
o EMC testing for CE and FCC in progress
• One year warranty
MXH94x Maximum DC current across input voltage ranges
MXH94X
#FireFly™
12V
3.3V
VAUX
1
1.97 A
0.84 A
0.35 A
2
2.30 A
0.84 A
0.35 A
3
2.62 A
0.84 A
0.35 A
4
2.95 A
0.84 A
0.35 A
MXH95x Maximum DC current across input voltage ranges
MXH95X
#FireFly™
12V
3.3V
VAUX
1
1.76 A
0.84 A
0.35 A
2
1.88 A
0.84 A
0.35 A
3
2.00 A
0.84 A
0.35 A
4
2.12 A
0.84 A
0.35 A
Note:
25 W Slot specification for +12V rail is 2.1 A max.
75 W slot specification for +12 V rail is 5.5 A max.
