Solar Pump Inverter Chapter 4 Function Parameters
29
Code Name Description
Factory
Default
Attri
bute
F02.26
Motor overload
protection
0: no protection
1: ordinary motor(with low speed
compensation)
2: variable frequency motor(without
low speed compensation)
2 ☆
F02.27
Motor overload
protection factor
20.0~120.0% 100.0% ○
F03 Group: Reserved
F04 Group: V/F control
F04.00 V/F curve
0: straight line V/F curve
1: multi-dots V/F curve
2: 1.3
th
power low torque V/F curve
3: 1.7
th
power low torque V/F curve
4: 2.0
nd
power low torque V/F curve
5: V/F separated curve
4 ☆
F04.01
Motor 1 Torque
Boost
0.0% (automatic)0.1%~10.0% 1.0% ○
F04.02
Motor 1 Torque
Boost to Stop
0.0%~50.0% 20.0% ○
F04.03 V/F frequency 1 0.00Hz～F04.05 0.00Hz ○
F04.04 V/F voltage 1
0.0%～110.0% (motor rated
voltage)
00.0% ○
F04.05 V/F frequency 2 F04.03～F04.07 00.00Hz ○
F04.06 V/F voltage 2
0.0%～110.0% (motor rated
voltage)
00.0% ○
F04.07 V/F frequency 3
F04.05～F02.02 (motor rated
frequency)
00.00Hz ○
F04.08 V/F voltage 3
0.0%～110.0% (motor rated
voltage)
00.0% ○
F04.09
Slip compensation
gain
0.0～200.0% 100.0% ○
F04.10
Low frequency surge
suppression factor
00～100 10 ○
F04.11
High frequency surge
suppression factor
00～100 10 ○
F04.12
Frequency threshold
of surge suppression
0.00Hz～F00.03 (Max. frequency) 30.00 Hz ○
F04.27 Voltage setting
0: Keypad setting
1: AI1 voltage setting
2~10:Reserved
0 ○
F04.28
Keypad setting
voltage
0.0%～100.0% 100.0% ○
F04.29 Voltage ACC time 0.0s～3600.0s 5.0s ○
F04.30
Voltage DEC time
0.0s
～
3600.0s
5.0s
○
F04.31
Max. V/F separated
voltage
F04.32～100.0% 100.0% ☆
F04.32
Min. V/F separated
voltage
0.0%～F04.31 0.0% ☆
