Solar Pump Inverter Chapter 4 Function Parameters
30
Code Name Description
Factory
Default
Attri
bute
F04.33
Weak magnetic
coefficient of
constant power zone
1.00~1.30 1.00 ○
F05 Group: Input terminal
F05.01
Terminal DI1
Function Selection
0: disabled
1: forward run
2: reverse running
3: three-wire running
4: forward jogging
5: reverse jogging
6: freewheel stop
7: fault reset
8: emergency stop
9: external fault input
21: ACC/DEC time selection 1
22: ACC/DEC time selection 2
30: ACC/DEC disabled
36: switch command to keypad
36: switch command to terminal
36: switch command to
communication
40: power consumption clear
41: power consumption stay
42: PV Inverter Forbid
43: Full-Water
44: Dry -Water
1 ☆
F05.02
Terminal DI2
Function Selection
43 ☆
F05.03
Terminal DI3
Function Selection
44 ☆
F05.04
Terminal DI4
Function Selection
42 ☆
F05.05
Terminal DI5
Function Selection
0 ☆
F05.10
Terminal DI1~DI5
Positive/Negative
Logic
0x00~0x1F 0x004 ☆
F05.11
DI Terminal Filtering
Time
0.000~1.000s 0.010s ○
F05.12
Virtual terminal
setting
0:virtual terminal invalid
1:MODBUS communication virtual
terminal valid
0 ☆
F05.13
Terminal control
running mode
0: two-wire control mode 1
1: two-wire control mode 2
2: three-wire control mode 1
3: three-wire control mode 2
0 ☆
F05.14 Delay time of DI1 on 0.000~50.000s 0.000s ○
F05.15
Delay time of DI1 off
0.000~50.000s
0.000s
○
F05.16 Delay time of DI2 on 0.000~50.000s 0.000s ○
F05.17
Delay time of DI2 off
0.000~50.000s
0.000s
○
F05.18 Delay time of DI3 on 0.000~50.000s 0.000s ○
F05.19
Delay time of DI3 off
0.000~50.000s
0.000s
○
F05.20 Delay time of DI4 on 0.000~50.000s 0.000s ○
F05.21
Delay time of DI4 off
0.000~50.000s
0.000s
○
F05.22 Delay time of DI5 on 0.000~50.000s 0.000s ○
F05.23
Delay time of DI5 off
0.000~50.000s
0.000s
○
