Solar Pump Inverter Chapter 4 Function Parameters
31
Code Name Description
Factory
Default
Attri
bute
F05.32
AI1 lower limit
0.00V~F05.34
0.00V
○
F05.33
Corresponding
setting of AI1 lower
limit
-100.0%~100.0% 0.0% ○
F05.34
AI1 upper limit
F05.32~10.00V
10.00V
○
F05.35
Corresponding
setting of AI1 upper
limit
-100.0%~100.0% 100.0% ○
F05.36
AI1 input filter time
0.000s~10.000s
0.100s
○
F05.37 AI0 lower limit 0.00V~F05.39
0.00V
○
F05.38
Corresponding
setting of AI0 lower
limit
-100.0%~100.0% 0.0% ○
F05.39 AI0 upper limit F05.37~10.00V
10.00V
○
F05.40
Corresponding
setting of AI0 upper
limit
-100.0%~100.0% 100.0% ○
F05.41 AI0 input filter time 0.000s~10.000s
0.100s
○
F06 Group: Output terminal
F06.03
Relay T1 Output
Function
0：Disabled
1: running
2: forward running
3: reverse running
4: jogging
5: inverter fault
6: frequency level detection FDT1
7: frequency level detection FDT2
8: frequency arrival
9: zero speed running
10: upper limit frequency arrival
11: lower limit frequency arrival
12: running ready
14: overload early warning
15: under-load early warning
20:external fault valid
22: running time arrival
23: MODBUS communication virtual
terminal output
1 ○
F06.04
RelayT2 Output
Function
5 ○
F06.05
Output Terminal
Positive/Negative
Logic
0x0~0x1F 0x0 ○
F06.10
Relay T1 Output
delay time
0.000~50.000 0.000s ○
F06.11
Relay T1 Disconnect
delay time
0.000~50.000 0.000s ○
F06.12
Relay T2 Output
Delay Time
0.000~50.000 0.000s ○
F.6.13
Relay T2 disconnect
Delay Time
0.000~50.000 0.000s ○
