Solar Pump Inverter Chapter 4 Function Parameters
32
Code Name Description
Factory
Default
Attri
bute
F07 Group: HMI interface
F07.00 User Password 0~65535 0 ○
F07.02
MF key function
selection
0:invalid
1: jogging running
2:left-shift key to switch display state
3: FWD/REV switch
4: clear UP/DOWN setting
5: freewheel stop
6: switch command methods in
order
7: non-factory parameter debugging
1 ☆
F07.03
MF key switch
command method
order
0: keypad
→terminal→communication
1: keypad←→terminal
2: keypad←→communication
3: terminal←→communication
0 ○
F07.04
STOP/RESET key
stop function
0: only valid for keypad control
1: valid for keypad and terminal
control at the same time
2: valid for keypad and
communication control at the same
time
3: valid for all control modes
0 ○
F07.05
Running Status
Display Selection
0x0000~0xFFFF
BIT0：Output frequency
BIT1：Reference frequency
BIT2：DC bus voltage
BIT3：Output voltage
BIT4：Output current
BIT5：Rotation speed
BIT6：Output power
BIT10: input terminal status
BIT11: output terminal status
0x05F ○
F07.06
Running Status
Display Selection 2
0x0000~0xFFFF
BIT0: Analog AI1(V light on)
BIT1: Analog AI2(V light on)
BIT2: Analog AI3(V light on)
BIT3~BIT15: Reserved
0x0000 ○
F07.07
Stop Status Display
Selection
0x0000~0xFFFF
BIT0：Reference frequency
BIT1：DC bus voltage
BIT2：Input terminal status
BIT3：Output terminal status
BIT7: Analog AI1(V light on)
BIT8: Analog AI2(V light on)
BIT9: Analog AI3(V light on)
0x00FF ○
F07.08
Frequency display
coefficient
0.01~10.00
Display frequency=running
frequency* F07.08
1.00 ○
