Solar Pump Inverter Chapter 4 Function Parameters
37
Code Name Description
Factory
Default
Attri
bute
F14.05
Communication
timeout error
handling
0: alarm and coast to stop
1: no alarm and continue running
2: no alarm and stop according to
stop mode (communication
mode is valid)
3: no alarm and stop according to
stop mode (all control modes are
valid)
0 ○
F14.06
Communication
processing actuation
selection
LED ones
0: write with response
1: write without response
LED tens
0: set value unsaved after power
off
1: set value saved after power off
0x00 ○
F15 Group Solar inverter special function
F15.00 PV Inverter Selection
0：Disabled
1：Enabled
2：Boost enabled (CT112A special)
1
(CT112)
2
(CT112A)
○
F15.01
Vmpp Voltage
Selection
0：Constant Voltage
1：Max. Power Point Tacking(MPPT)
2
：
Bus voltage *0.85
1 ○
F15.02
Vmpp Voltage
Keypad Set
0.0~6553.5Vdc
555.0V or
200.0V
Depend on
mode
○
F15.03
PID Off Set Limits
0.0~100.0%(100.0% refer P11.18)
0.0%
☆
F15.04
PID Max. Output
Frequency
0~100.0% 100.0% ○
F15.05
PID Min. Output
Frequency
0.0%~100.0% 0.0% ○
F15.06 KP1 0.00~100.00
1.0
(CT112)
10.0
(CT112A)
○
F15.07 KI1 0.00~100.00
1.0
(CT112)
10.0
(CT112A)
○
F15.08 KP2 0.00~100.00
15.00
(CT112)
10.00
(CT112A)
○
F15.09 KI2 0.00~100.00
15.00
(CT112)
10.00
(CT112A)
○
