Control unit
e unit has the following control elements:
1. Emergency stop/on switch (1)
2. Main drive on/rotation direction switch (2)
3. Take-up block on/rotation direction switch (3)
4. Main drive speed control knob (4)
5. Take-up block speed control knob (5)
Main
drive
Take-up
block
1
3
4
5
Power
supply
2
