4
CCC Ducted Installation Instructions
MODEL NOMINAL ELECTRICAL COMPRESSOR COMPRESSOR FAN MOTOR FAN MOTOR SCFM-HIGH TOTAL REFRIGERANT MINIMUM AC CIRCUIT INSTALLED MINIMUM NO. CAPACITY RATING RATED LOAD LOCKED RATED LOAD LOCKED SPEED STATIC R-22 (OZ) WIRE SIZE* PROTECTION WEIGHT GENERATOR (BTU/HR) AMPS ROTOR AMPS ROTOR MAX/MIN MAX/MIN *** USER (POUNDS) SIZE** COOLING AMPS AMPS “ W. C. SUPPLIED 1 UNIT/ 2 UNITS 59136.336 15,000 12.7 60.0 2.5 6.0 325 / 250 0.40 / 1.10 34.0 20 Amp 102 3.5 KW / 5.0 KW 59136.521 15,000 12.9 71.0 2.5 6.0 325 / 250 0.40 / 1.10 34.5 20 Amp 102 3.5 KW / 5.0 KW 59136.531 15,000 12.8 79.0 2.5 6.0 325 / 250 0.40 / 1.10 31.5 20 Amp 102 3.5 KW / 5.0 KW 59136.536 15,000 12.8 79.0 2.5 6.0 325 / 250 0.40 / 1.10 31.5 20 Amp 102 3.5 KW / 5.0 KW 59136.621 15,000 12.0 77.0 2.5 6.0 325 / 250 0.40 / 1.10 34.5 20 Amp 102 3.5 KW / 5.0 KW 59136.631 15,000 12.0 77.0 2.5 6.0 325 / 250 0.40 / 1.10 34.5 20 Amp 102 3.5 KW / 5.0 KW 59516.303 15,000 12.7 60.0 2.0 5.6 325 / 250 0.40 / 1.10 29.0 20 Amp 101 3.5 KW / 5.0 KW 59516.331 15,000 12.7 60.0 2.5 5.8 325 / 250 0.40 / 1.10 29.0 20 Amp 101 3.5 KW / 5.0 KW 59516.336 15,000 12.7 60.0 2.0 5.6 325 / 250 0.40 / 1.10 29.0 20 Amp 101 3.5 KW / 5.0 KW 59516.501 15,000 12.9 71.0 2.5 6.0 325 / 250 0.40 / 1.10 31.0 20 Amp 101 3.5 KW / 5.0 KW 59516.506 15,000 12.9 71.0 2.5 6.0 325 / 250 0.40 / 1.10 31.0 20 Amp 101 3.5 KW / 5.0 KW 59516.531 15,000 12.7 79.0 2.0 5.6 325 / 250 0.40 / 1.10 29.0 20 Amp 101 3.5 KW / 5.0 KW 59516.536 15,000 12.7 79.0 2.0 5.6 325 / 250 0.40 / 1.10 29.0 20 Amp 101 3.5 KW / 5.0 KW 59516.601 15,000 12.9 77.0 2.5 6.0 350 / 250 0.40 / 1.10 31.0 20 Amp 101 3.5 KW / 5.0 KW 59516.603 15,000 12.3 77.0 2.0 5.6 325 / 250 0.40 / 1.10 29.5 20 Amp 101 3.5 KW / 5.0 KW 59516.606 15,000 12.9 71.0 2.5 6.0 325 / 250 0.40 / 1.10 31.0 20 Amp 101 3.5 KW / 5.0 KW 59516.631 15,000 12.3 77.0 2.0 5.6 325 / 250 0.40 / 1.10 29.5 20 Amp 101 3.5 KW / 5.0 KW 59516.731 15,000 13.3 62.0 2.0 5.6 325 / 250 0.40 / 1.10 29.0 20 Amp 101 3.5 KW / 5.0 KW 59528.601 N/A 6.0 45.6 2.0 5.6 325 / 250 0.40 / 1.10 16.5 15 Amp 92 3.5 KW / 5.0 KW 59529.531 N/A 6.9 49.0 2.0 5.6 325 / 250 0.40 / 1.10 18.5 15 Amp 94 3.5 KW / 5.0 KW 59529.601 N/A 8.0 48.3 2.0 5.6 325 / 250 0.40 / 1.10 19.0 15 Amp 94 3.5 KW / 5.0 KW 59529.631 N/A 8.0 48.3 2.0 5.6 325 / 250 0.40 / 1.10 19.0 15 Amp 94 3.5 KW / 5.0 KW 59530.531 N/A 7.8 53.0 2.0 5.6 325 / 250 0.40 / 1.10 19.0 15 Amp 94 3.5 KW / 5.0 KW 59530.532 N/A 8.0 53.0 2.5 5.8 325 / 250 0.40 / 1.10 18.5 15 Amp 94 3.5 KW / 5.0 KW 59530.536 N/A 7.8 53.0 2.0 5.6 325 / 250 0.40 / 1.10 19.0 15 Amp 94 3.5 KW / 5.0 KW 59530.601 N/A 8.0 48.3 2.0 5.6 325 / 250 0.40 / 1.10 19.0 15 Amp 93 3.5 KW / 5.0 KW 59530.631 N/A 8.0 48.3 2.0 5.6 325 / 250 0.40 / 1.10 19.0 15 Amp 94 3.5 KW / 5.0 KW 59530.632 N/A 8.5 48.3 2.5 5.8 325 / 250 0.40 / 1.10 18.0 15 Amp 94 3.5 KW / 5.0 KW 600312.321 11,000 9.5 53.0 3.1 8.8 335 / 250 0.12 / 0.65 16.5 20 Amp 95 2.5 KW /4.0 KW 600312.421 11,000 10.7 50.0 3.1 8.8 335 / 250 0.12 / 0.65 16.0 20 Amp 101 2.5 KW / 4.0 KW 600315.321 13,500 12.4 60.0 3.1 8.8 335 / 250 0.12 / 0.65 15.5 20 Amp 96 3.5 KW / 5.0 KW 600315.326 13,500 12.4 60.0 3.1 8.8 335 / 250 0.12 / 0.65 15.5 20 Amp 102 3.5 KW / 5.0 KW 600315.421 13,500 11.5 50.0 3.1 8.8 335 / 250 0.12 / 0.65 17.0 20 Amp 102 3.5 KW / 5.0 KW
SPECIFICATIONS
115 VAC, 60 HZ., 1PH.
12 AWG Copper up to 24’
* For wire lengths over 24 ft. consult the National Electric Code for proper sizing. ** Dometic Corporation gives GENERAL guidelines for generator requirements. These come from experiences people have had in actual applications When sizing the generator, the total power usage of your recreational vehicle must be considered. Keep in mind generators lose power at high altitudes and from lack of maintenance. *** CIRCUIT PROTECTION: Time Delay Fuse or HACR Circuit Breakers Required.
