Dometic CU402 - Page 23

FIGURES AND
TECHNICAL DRAWINGS
EN
23
486 mm
336 mm
35 mm
FO311
FRONT VIEW SIDE VIEW
MIN. 480 mm
500 mm
460 mm 460 mm
528 mm
478 mm
503 mm
520 mm
88 mm
370 mm
PI0913
PI0913A
248 mm
248 mm
233 mm
179 mm179 mm
233 mm
R7
0 mm
R7
0 mm
135°
135°
358 mm
466 mm
R3
0
mm
R30
mm
R3
0 mm
R3
0
mm
PI8002
PI8022
480 mm
80 mm
370 mm
