CV1004 Installing the vacuum cleaner
13
7 Installing the vacuum cleaner
!
A
➤ Ensure that the dust bag and the motor filter are in place.
➤ Check the vacuum cleaner works prior to installation.
A
➤ Mount the vacuum cleaner (fig. 4 , page 4 to fig. 0, page 5).
I
➤ Mount the hose socket and route the connection hose (fig. a, page 5,
and fig. b, page 5).
WARNING! Danger of electrocution and serious injury.
Beware of electrical cables in the wall when drilling and sawing.
NOTICE!
Mount the vacuum cleaner in a dry place.
Do not mount the vacuum cleaner in an area which is subject
to high temperatures.
Do not bend the connection cable round sharp edges or cor-
ners. Keep the connection cable away from heated surfaces.
To install the vacuum cleaner, the wall thickness must be a
minimum of 10 mm and a maximum of 25 mm.
Ensure there is a socket nearby which can be used to supply
the vacuum cleaner with power. Do not use extension cables.
If the vacuum cleaner is being installed in small spaces with
poor ventilation (e.g. cabinet), then an air outlet and an air out-
let grille with a cross-section of 70 mm must be installed in
order to transport warm air generated by the device outside.
NOTICE!
The bolts on the housing must not be screwed out completely
because they are fitted with a spring mechanism.
NOTE
The mounting connectors (fig. 3 1, page 4) need to be glued on
the device-side using a standard adhesive. The screw connectors
(fig. 3 2, page 4) are screwed into the connection hose and
inserted into the mounting connectors.
