LITERATURE NUMBER MPD 32267
INFORMATION NOTICE
FUSE AND CIRCUIT
FURNACE SERIES AFS, AFM
Effective 9/16
This Information Notice addresses installation and management of the electrical circuit for furnace
appliances for all Atwood Mobile Products, LLC to avoid circuit overload and possible fuse blows.
All furnaces must be wired on a dedicated circuit not more than 15 amps Furnace
installation must follow all applicable state and local codes!
CAUTION
Make sure all wire connections are tight and protected from damage to reduce over-heating of
connections when repairing wiring.
Changes to Atwood’s rating plates and installation instruction are as shown below.
Sample change to Rating Plate location
on top of furnace.
Sample change within the Installation Manuals.
Models
AFMD16
AFMD20
AFMD25
AFMD30
AFMD35
Type of
Gas
LP
Propane
LP
Propane
LP
Propane
LP
Propane
LP
Propane
BTU Input
16,000
20,000
25,000
30,000
34,000
BTU
Output
12,160
15,200
19,000
22,800
25,840
Duct
Static
Pressure
.20”
WC*
.10” WC*
.10” WC*
.10” WC*
.10” WC*
Amperage
(AMPS)
4.2**
4.2**
7.5**
7.5**
11.1**
Watts
50
50
90
90
132
Power
Supply
(Volt DC)
12
12
12
12
12
Return Air
80 in
2
80 in
2
80 in
2
80 in
2
80 in
2
Minimum
Return Air
65 in
2
65 in
2
65 in
2
65 in
2
65 in
2
MODEL SPECIFICATIONS
* (WC = WATER COLUMN)
** Furnaces must be wired on a dedicated circuit not more than
15 amps. Furnace installation must follow all applicable state
and local codes!
