Dometic DMR702 - Clearances; Overall and Recess Dimensions

- 6 -
G
K K
L
M
CLEARANCES
Minimum clearances (in inches) to combustible materials:
Top (G) 0
Side (K) 0
Bottom (L) 0
Rear (M
1
) 0
1
The distance between the rear most part of the refrigerator and the wall
behind it.
MODEL
DATA
DMR/DMC
OVERALL DIMENSIONS
Height (A) mm 1391
inches 54-3/4
Width (B) mm 637
inches 25-5/64
Depth (C) mm 668
inches 26-19/64
RECESS DIMENSIONS
Height (H) mm 1365
inches 53-3/4
Width (W) mm 602
inches 23-11/16
Depth (D) mm 616
inches 24-1/4
SIDE VIEW
B
C
VIEW FROM ABOVE
D
H
A
D
W
B
C
OVERALL AND RECESS DIMENSIONS
A
VENTILATION REQUIREMENTS
B2
UPPER & LOWER SIDE VENT
Fan(s)*
Minimum
Ventilation
Height
* Fan(s) position may vary by model.
