K. REMOVING THE TURNTABLE MOTOR
(1) Remove the turntable.
(2) Remove the turntable shaft VERY CAREFULLY
with a slotted screwdriver. (Figure 21)
(3) Remove the base plate by removing 6 screws
securing it to the oven cavity. (Figure 22)
(4) Disconnect the leadwire from the turntable motor
terminals.
(5) Remove the 2 screws securing the turntable motor
to the oven cavity ASS'Y. (Figure 23)
NOTES:
• Remove the leadwire from the turntable motor VERY
CAREFULLY.
• Be sure to grasp the connector not the wires when
removing.
Wire Leads
Turntable Motor
Figure 23
Figure 21
Figure 22
7-11
