7-19
(2) CHECKOUT PROCEDURES FOR RELAY.
- PROBLEM (A) -
T.T. motor and oven lamp turn on without touching
START key when the door is closed.
Remove the mate connector of I/O
CON from the circuit board.
Does the unit still operate?
GOOD
Replace the
circuit board
Replace
RELAY3
- PROBLEM (B) -
T.T. motor and oven lamp turn on When the door is
closed and START key is touched.
Measure the voltage at pin NO.
4 of U01
Voltage reading: 0 Vdc
Replace the
circuit board
Defective
RELAY3 or poor
connection of
RELAY3
Defective
RELAY3
Replace
RELAY3 or correct
the connection.
NO
NO
YES
YES
NO
NO
YES
YES
GOOD
To Next Page
