GY11 Mounting the roof vent
9
6 Mounting the roof vent
Note on installation location
• The vent should be mounted on the roof on a level surface. When mounted on a
sloping surface, the roof hood must be rotated so that one of the three water
drainage holes is directed toward the incline. A tilt angle up to 20° will not affect
the performance of the vent when the motor is not running.
• The vent removes air from the interior. Make sure there is an adequate air supply!
The air intake opening must be at least 60 cm
2
.
Mounting the vent
➤ Select an appropriate installation location for the vent on the roof.
➤ Provide an opening for a three-step switch (not included in scope of delivery), for
example at the kitchen unit.
➤ Draw the location and size of the opening of 105 mm diameter for the vent
(fig. 2, page 3) and for the opening of the switch.
➤ Pre-drill and cut out the holes on the roof carefully with a keyhole saw or similar
tool.
➤ Place the vent (fig. 3 3, page 4) on the opening (fig. 3 5, page 4) and mark
the six screw holes.
➤ Apply a thin ring of a permanently elastic sealing material around each hole.
➤ Put the rubber seal (fig. 3 4, page 4) into the groove on the underside of the
vent.
➤ Attach the vent (fig. 3 3, page 4) with six bolts (4,2 x 25).
I
➤ Attach the roof hood (fig. 3 2, page 4) with three bolts (3,5 x 9,5).
➤ Attach the cover cap (fig. 3 1, page 4) with three bolts (4,2 x 13).
➤ Attach the switch next to the stove.
NOTE
Pull the vent on tightly enough that the rubber seal is seamlessly in
contact with the roof.
