Installing and connecting the refrigerator HC302D, HC502D
18
6.3 Installing built-in version
!
Observe the following instructions when installing:
• Install the refrigerator so that the warm air produced can easily flow away (either
upwards or to the front, fig. 3, page 4).
Key to fig. 3, page 4
• Make sure that the refrigerator door is able to open at least 100°. Otherwise the
drawers cannot be used.
➤ Check the dimensions of the device (fig. a, page 8 or fig. b, page 9).
➤ Place the device according to fig. 4, page 5 or fig. 5, page 5.
➤ Mount the device to the furniture by two screws through the fittings at the bottom
(fig. 6, page 6).
➤ Leave the device to stand for at least four hours before you connect it to the
power supply so that the refrigerant can flow back into the compressor.
CAUTION!
Ensure the shelf is adequate to carry the total weight of the refrigerator
and the medicinal products to be stored.
No. Explanation
1 Cold intake air
2 Hot waste air
HC302D-502D-IO-WEST.book Seite 18 Freitag, 17. März 2017 2:15 14

Dometic HC302D Specifications

General

Noise level	45 dB
Certification	CB, CE, DIN 58345
Climate class	SN
Fridge net capacity	22 L
Fridge gross capacity	33 L
Fridge temperature range	2 - 8 °C
Connected load	70 W
AC input voltage	230 V
AC input frequency	50 Hz
Annual energy consumption	- kWh
Door hinge	Right
Control type	Buttons
Product color	White
Built-in display	Yes
Shelves material	Metal
Appliance placement	Freestanding
Refrigerating medium	R134a
Number of vegetable drawers	-
Refrigerating medium weight	38 g
Fridge number of shelves/baskets	3
Lamp type	LED
Package depth	504 mm
Package width	475 mm
Package height	640 mm
Package weight	22000 g

Weight and Dimensions

Depth	450 mm
Width	422 mm
Height	580 mm
Weight	20000 g
Width with door open	820 mm
