Typical NPT fittings
Typical ORB fittings
Typical ORB fittings
8.3 Fitting identification
NOTICE!
Liquid thread sealant is used on the NPT side of these fittings only.
NOTICE!
No sealant is used on either side of ORB fittings.
NOTICE!
The 3/8 tube side of the fittings are the same for NPT and ORB fittings
and SeaStar hoses will fit both.
Figure 8-3.
Figure 8-4.
Figure 8-5.
1/4” NPT
3/8” TUBE
1/4” NPT
3/8”
TUBE
1/4”
NPT
3/8” TUBE
Straight Fitting Elbow Fitting 45° Fitting
Straight Fitting Elbow Fitting 45° Fitting
-5 ORB
3/8"
TUBE
-5 ORB
3/8"
TUBE
-5 ORB
3/8"
TUBE
-5 ORB
3/8"
SAE
NPT ORB
3/8" NPT
45° FLARE
3/4” UNF
BLEED
NIPPLE
