Setting up and connecting the refrigerator HiPro
22
Then proceed as follows (fig. 5, page 6 until fig. 9, page 8):
HiPro4000, HiPro4000Vision (for version with high feet)
➤ Unscrew the high feet.
HiPro3000, HiPro4000, HiPro6000, HiPro4000Vision
➤ Pull the lower hinge out.
➤ Pull the door with the hinges out.
➤ Remove the hinge pins.
➤ Insert the hinge pins on the other side again.
➤ Insert the door with the lower hinge again.
I
HiPro4000, HiPro4000Vision (for version with high feet)
➤ Screw on the high feet again.
7.5 Install sliding hinge
➤ Observe the distances in fig. 0, page 9.
➤ Proceed as displayed infig. a, page 9 until fig. b, page 10.
7.6 Install panel plate
➤ Observe the installation dimensions in fig. c, page 10.
➤ Remove the retaining ring of the lock (optional, fig. d, page 11).
➤ Proceed as displayed infig. d, page 11 until fig. e, page 11.
NOTE
HiPro4000Vision: Insert the door rotated by 180°.
