10. Key on and power up the i7X00 system.
11. Reconnect to the system using Datalink. (It may take a
moment for the components to become visible in Datalink)
12. Verify that the latest revision of rmware was loaded to the
component as per Section D.1.
13. Repeat steps 5 through 13 for any other components which
may require updating.
NOTE: In some cases, conguration values may need to be manually
re-entered after an update. The readme les will instruct to do so if
necessary so ALWAYS read the readme le prior to updating.
NOTE: When opening component windows in Datalink, it is good
practice not to have more than two components open at a time to
avoid potential communication errors.
NOTE: When updating components, it is common to have warning
indications on the control head. These can be ignored, but no active
faults should be present after completion of the updating process.
The CANtrak software can only be updated from the display. You
will need a USB drive (preferably empty) and a computer to perform
the update.
D.3 Updating the CANtrak Software
Procedure
1. If you haven’t already done so, download and install the le
updater (page D-1).
2. Find the Optimus Firmware folder on your desktop and open it,
then open the Color CANtrak folder.
3. In the Color CANtrak folder you will nd a .zip le. Double-click
on it to view the les in the folder.
4. Copy all the les to the root level of your USB drive. Don’t put
them in a le folder.
5. Plug the USB drive into the port on the back of the CANtrak. If
your system is off, turn it on now.
6. The software update process is automatic. When prompted,
remove the USB drive from the display. The display will reboot
into the updated software version.
7. Delete the les you copied to the USB drive. If you don’t, you
won’t be able to use the USB drive for other CANtrak functions.
