Dometic MasterFlush 8740 User Manual

5
Dometic 8700 Series MasterFlush Toilet Components
3 Components
(g.
1
, page 2)
Ref. Description
A Macerator toilet
B Dometic DFT ush switch
C Control module
D 4-wire cable to toilet macerator
pump and water valve
E Cable for Dometic DFT ush switch
or DSS status panel (RJ45/ethernet)
F Cable to toilet’s electronic ush
handle (for ush handle model)
G Incoming electrical power wires
H
Power wires to raw water pump (opt.)
I Wire for “3/4-full tank” signal
J Wire for “full tank” signal
K Floor mounting hardware kit
L Floor mounting template
M Flush handle (for ush handle model)
N Dometic DSS status panel
(for ush handle model)
O
Cable for ush handle and other mfr.
status panel (for ush handle model)
Ref. Description
1 Anti-siphon valve
2 Vacuum breaker
3 Discharge loop outlet
4 Discharge adapter tting
5 Discharge hose tting
6 Macerator pump
7 Water valve
8
Water line - 0.5 in. NPT tting
9 4-pin cable connector
10 Flush handle
(on ush handle model only)
11 Flush handle cable connector
Refer to complete parts list (packed separately)
for additional information.
(g.
2
, page 2)
