Micro Heki Mounting the Micro Heki
7
7Mounting the MicroHeki
Supplementary to fig. 3
➤ Measure your roof thickness W.
➤ Use the appropriate installation kit.
See fig. 4
➤ Check that the roof light has sufficient space around it (approx.1 to 2 mm) in the
wall section.
See fig. 5
➤ Clean the roof opening in the mounting area.
See fig. 6
A
➤ Seal the mounting frame with a flexible non-hardening sealing compound (e.g.
SikaLastomer-710).
W W
23 – 25 mm 9104118048 43 mm 9104118048 + 9104118059
26 – 27 mm 9104118049 44 – 45 mm 9104118049 + 9104118059
28 – 29 mm 9104118050 46 – 47 mm 9104118050 + 9104118059
30 – 31 mm 9104118051 48 – 49 mm 9104118051 + 9104118059
32 – 33 mm 9104118052 50 – 51 mm 9104118052 + 9104118059
34 – 35 mm 9104118053 52 – 53 mm 9104118053 + 9104118059
36 – 37 mm 9104118054 54 – 55 mm 9104118054 + 9104118059
38 – 39 mm 9104118055 56 – 57 mm 9104118055 + 9104118059
40 – 41 mm 9104118056 58 – 59 mm 9104118056 + 9104118059
42 mm 9104118057 60 mm 9104118057 + 9104118059
NOTICE!
Observe the sealant manufacturer's instructions.
