nDR1292
Install the screws in the following order:
(shipped as a loose part). Attach the front strip after
the refrigerator is set into the cutout opening.
Install the
lower front
strip by slid-
ing it under
the bottom
hinge plate.
Secure the
refrigerator and
the lower front
strip with two
screw through
each hinge.
the four screws that secure the
top decoration panel to the
top frame. Two screws are ac-
cessible from underneath and
two are located on each side of
for reinstallation of the top decoration panel.
3.
1.
a)
b)
2.
a)
b)
3.
Rm2451, Rm2454, Rm2551, Rm2554, Dm2652,
Dm2662, Dm2663, Dm2852, Dm2862, Dm3862 &
nDm1062
Install the screws in the following order:
(shipped as a loose part). Attach the front strip after
the refrigerator is set into the cutout opening.
Install the lower front strip by sliding it under the
bottom hinge plate. The hinge plate can be on the
right or left side depending on the door swing.
hinge, the part is possible to swing into place.
Secure the refrigerator and the lower front strip
on the opposite side and then, one screw through
the lower front strip.
tabs out of the hole in the hinge
(both sides).
Carefully tilt the top decoration
top frame. Be careful not to
damage the circuit board and wires.
Install the two screws in the top frame, the holes
are accessible from underneath.
Seal the opening for the screws with aluminum
tape.
Replace the top decoration panel. Be careful not
1.
a)
b)
2.
a)
b)
c)
d)
e)
