PW1000, PW1500, PW1750 Installing the awning
9
Installing the awning with mounting plates
➤ Select the location of the installation.
In particular, check that there is enough space in the interior to mount the counter
plates at the points where the screws will be.
I
➤ Align the mounting plates on the vehicle and mark where the holes are to be
drilled (fig. 8, page 1).
➤ At the marked points, drill holes with a diameter of 6.5 mm from the outside
through the external wall.
➤ Clean the outer sides of the mounting plates and the installation surface on the
vehicle.
➤ Fill the drill holes in the vehicle wall with an acid-free silicone.
➤ Insert the square-head bolts through the relevant holes in the mounting plates
(fig. 9, page 1).
➤ To glue and seal, apply an elastic adhesive, such as Sikaflex
®
-221 for example, to
the back of the mounting plates (fig. 9, page 1).
➤ Place all of the mounting plates through the drill holes and fasten them with
counter plate, serrated lock washers and hexagon head bolts (fig. 0, page 1).
➤ Only for awnings with a width of 2.6 m to 3.5 m:
Fasten all of the mounting plates using a countersunk bolt, counter plate,
serrated lock washer and hexagon nut (fig. a , page 1).
➤ Only for awnings with a width of 4 m to 5.5 m:
Fasten the inner (narrow) mounting plates using a countersunk bolt, counter
plate, serrated lock washer and hexagon nut (fig. a, page 1).
➤ Wait until the glue has set. For further details, please refer to the information
provided by the sealant manufacturer.
➤ Use two people to hook the awning on to the mounting plates (fig. b, page 1).
➤ Extend the awning about 50 cm using the crank.
NOTE
Recommended mounting position for each counter plate: fig. 7,
page 1.
