Important safety and installation instructions PW1000, PW1500, PW1750
4
2 Important safety and installation
instructions
Please observe the safety instructions and stipulations issued by the
vehicle manufacturer and service workshops.
The manufacturer accepts no liability for damage in the following cases:
•
Faulty assembly or connection
•
Damage to the product resulting from mechanical influences
•
Alterations to the product without express permission from the manufacturer
•
Use for purposes other than those described in the operating manual
!
WARNING!
•
If you do not have sufficient technical knowledge for installing
components in vehicles, you should have a specialist fit the awning to
your vehicle.
3Scope of delivery
No. in
fig. 1,
page 1
Awning width
Description
2.6 m,
3 m, 3.5 m
4 m, 4.5 m 5 m, 5.5 m
1 1x 1x 1x Awning
2 – – 2x Mounting plate (400 mm)
3 – 2x 2x Mounting plate (160 mm)
4 2x 2x – Mounting plate (80 mm)
5 1x – – Mounting plate (35 mm)
6 5x 8x 12x Counter plate
7 5x 8x 12x Square-head bolt
8 2x 4x 6x Countersunk bolt
9 7x 12x 18x Serrated lock washer
10 7x 12x 18x Hexagon nut
11 5x 8x 12x Cover for the counter plate
12 11x 14x 18x Self-tapping screw
