Connecting the awning (PW1500 and PW1750) PW1000, PW1500, PW1750
14
Installing the receiver of the remote control and connecting the electrical
connections
➤ Find a suitable location inside the motor home, out of direct sunlight, to install the
mounting bracket for the remote control.
➤ Connect the motor with the remote control in accordance with the applicable
electrical engineering regulations and the circuit diagram (fig. m , page 2).
Programming the remote control and the wall switch
➤ Place the battery (see fig. n 1, page 2).
➤ Switch on the power supply.
✓ The receiver beeps once briefly.
➤ Press the programming button (fig. n 2, page 2) or the buttons and on
the wall switch simultaneously (fig. o 1 and 2, page 2) within 4 seconds.
✓ The receiver beeps once briefly.
➤ Press the programming button (fig. n 2, page 2) or the buttons and on
the wall switch simultaneously (fig. o 1 and 2, page 2) again briefly.
✓ The receiver beeps once briefly.
➤ Briefly press the button (fig. o 3, page 2).
✓ The receiver beeps four times briefly.
✓ The awning moves briefly.
Proceed as follows to pair the wall switch:
➤ Press the programming button (fig. n 2, page 2) twice.
✓ The receiver beeps twice briefly.
➤ Press the buttons and on the wall switch simultaneously (fig. o 1 and 2,
page 2).
✓ The receiver beeps five times briefly.
✓ The remote control or wall switch and awning are now set to one another.
PW1000_PW1500_PW1750-I-18s.book Seite 14 Dienstag, 12. Juni 2018 4:37 16
