PW1000, PW1500, PW1750 Connecting the awning (PW1500 and PW1750)
13
•
If you want to connect an awning light (accessory), make sure that its maximum
power consumption is 30 W. When connecting, make sure the polarity is
correct.
•
Observe the required cable cross section when connecting to the power supply:
Legend to fig. m, page 2:
Installing the wall switch
➤ Find a suitable location inside the motor home, out of direct sunlight, to install the
switch.
Cable length Required cable cross section
2 m 1.5 mm²
4 m 2.5 mm²
6 m 4.0 mm²
8 m 6.0 mm²
No. Description
1 Receiver
2 3 A fuse for LED awning light (optional)
3 on Orange line for D+ connection
4 rd Red line for LED awning light (optional)
5 bk Black line for LED awning light (optional)
6 bu Blue line for motor connection
7 bn Brown line for motor connection
8 bk Black line for power supply
9 rd Red line for power supply
10 Main switch
11 15 A fuse for main switch
