RC(S)(L)(D)10-Series Installing the refrigerator
15
3.2 Installing the condensation drain
I
Install the condensation drain as follows:
➤ Run the condensation hose from the refrigerator through an opening in the floor
which goes outside.
3.3 Connecting the power supply
A
➤ Determine the required cross section of the cable in relation to the cable length
according to fig. 4, page 5.
➤ Connect the cables to the AMP connector of the refrigerator (fig. 5, page 6).
➤ Connect the other ends of the cables to the
12 Vg power supply:
Refrigerator depth (C)
(excludes control knob
5 mm)
555 mm 610 mm
Recess height (H) 824 mm 824 mm
Recess width (W) 528 mm 528 mm
Recess depth (D) 558 mm 613 mm
NOTE
• Condensation can form inside the refrigerator due to frequent door
opening, incorrectly stored food or food that is stored when it is too
warm.
• Condensation must be drained with a constant slope.
NOTICE!
• The electrical installation and repairs may only be performed by a
specialist in accordance with the applicable national regulations and
standards.
• To avoid voltage loss and therefore a drop in performance, the cable
should be kept as short as possible and should not be interrupted if
possible. For this reason avoid additional switches, plugs or power
strips.
• Before connecting check whether the operating voltage and the
battery voltage correspond (see type plate).
RCS10.5(S)(T) RCS10.5X(S)(T)
DometicRCL10-RCD10-RCS10-RC10_INM _4445103136_EMEA18_202x-xx-xx.book Seite 15 Freitag, 2. Oktober 2020 7:40 19
