Installation RCD10.5XES
12
8.2 Installation with two rear vents
1. Keep the air inlet and outlet vents free from coverage by vehicle parts (such as an open door or by installing
accessories such as bicycle racks) while operating.
2. Install the refrigerator so that it is protected from excessive heat, as this leads to poor performance and
increases the power consumption of the refrigerator.
3. Perform the electrical installation compliant with national and local regulations.
Recess Overall dimension in mm
Height (A)1260
Width (B) 550
Depth (C)615
Recess Dimension in mm
Height (H) 1246–1251
Width (W) 526 – 531
Depth (D) 571 – 586
