Connecting the refrigerator RCD10.5XES
22
3. Connect the cable to the refrigerator DC terminal block (fig. e 1).
I
4. Connect the refrigerator with fuse protection fitted to the positive (+) side of the supply cable of 15 A (at 12 V)
or 7.5 A (at 24 V), with fuse fitted at the battery end of the cable.
9.2 Connecting the refrigerator to AC mains
D
➤ To connect the refrigerator to the AC mains, plug the connector into the AC socket.
NOTE
Connect the refrigerator as directly as possible to the battery to reduce the voltage
drop in the cable.
DANGER! Electrocution hazard
• Never handle plugs and switches with wet hands or if you are standing on a wet sur-
face.
• If the refrigerator is operated on a boat with an AC mains connection via a shore con-
nection, a residual current circuit breaker must be installed between the AC mains
and the refrigerator.
Seek advice from a qualified electrician.
