Refrigerator operation
Explanations :
Select the desired power supply by turning the
energy selector switch (1). The energy selector
switch has four settings :
n Off (1.)
n Mains voltage (230V AC) (2.)
n Off (3.)
n Gas (liquid gas propane/butane) (4.)
5.5.1 Explanation of operating
controls
Manual energy selection /
manual ignition Piezo-igniter :
5.5 Operation
1 = Power On switch / Energy selector switch
2 = Temperature controller
3 = Piezo-igniter (gas)
4 = Flame indicator (galvanometer)
2
1
3
4
5.5.3 Gas operation (liquid gas)
Prior to starting the refrigerator in gas
mode :
n Open the gas cylinder valve.
3. Activate Piezo ignition (3) several times at
intervals 1-2 second.
4. Once the flame ignites, the pointer of galva-
nometer (4) begins moving into the green
range. Keep knob (2) depressed for
approx. 15 seconds and finally release it.
The refrigerator is operational.
5.5.2 Electrical operation
Switch on the appli-
ance by turning the
energy selection
switch (1) clockwise
to position :
230V operation.
1. Turn the rotary selector switch (1) to
position
2. Turn the temperature selector (2) clockwise
and push. Keep the controller button
depressed.
gas operation.
