Power module (electronics)
230V-connection directly to power module
Terminal strip for 12VDC supply
Burner control device
Gas valve
Main connection gas supply
Gas burner (behind cover)
2
1
1
7
6
4
5
3
2
3
4
5
6
7
Fig. 7
Back side RM 8xxx
Description of model
