12
EN
Diagnostic Procedures Manual Refrigerator
Component Diagnostic Question Action Based On Status Page
Ventilation Fan/Switch
Does the refrigerator not get cold
enough in any operating mode?
1. Confirm that the temperature at the
ventilator fan switch is within the range
that will activate the ventilator fan.
I
Installation location varies by model
and installer. The temperature range for
activation varies by model.
2. If the temperature is within specification,
does the fan switch close the circuit.
3. If the circuit does not close, replace the
fan switch.
22
4. If the circuit closes, but the fan does not
activate, confirm that the voltage supplied
to the fan is between 10.5–22VDC.
13
5. If the voltage is within specification,
replace the fan.
22
