6
EN
Troubleshooting Manual Refrigerator
Operational Issue Potential Reason Page
There is a strong smell of ammonia. The cooling unit is defective. 9
There is a loud gurgling noise coming from
the cooling unit.
The cooling unit is defective.
Diagnostics Table
Component Page
Burner Assembly 8
Cooling Unit 9
Door 9
Electrode 9
Fan/Fan Switch 12
Flue Baffle 10
Gas Valve 10
Heating Element 10
Piezo 11
Switch (AC) 11
Switch (DC)
Thermocouple 11
Thermostat 11
Ventilation Fan/Switch 12
4 General Information
This section provides reference information on the tools,
components, and terminology associated with the
refrigerator.
4.1 Tools and Materials
Dometic recommends that the following tools and
materials be used while servicing the refrigerator:
Recommended Tools
Flat-Bladed Screwdriver Heat Gun
Multimeter - DC/AC
Amperage, DC/AC Voltage,
Millivolts, Ohms
Substance Temperature
Thermometer
U-Tube Manometer
Needle Nose Pliers Wrenches
Phillips Head Screwdriver
To Next Page
