MAXIMUM TOTAL CONDUCTOR WIRE LENGTH IN FEET/METERS
AWG
RM2410
RM2510
RM2610
RM2810
14
9
ft.
7 ft.
6.5 tt
6.5 n
2.7 m
2.1 m
2m
2m
12
15 ft.
12 ft.
10.5
n
10.5 ft.
4.6 m
3.6 m 3.2 m
3.2 m
10
25 ft.
19 ft.
17 ft
.
17 ft.
7.6 m
5.8 m 5.1 m
5.1 m
6
40 ft.
31 n 27n
27 ft.
12.2 m
9.5 m 8.1 m
8.1 m
Maximum
15 amps
20 amps
25 amps
25
amps
Fuse Size
Refrigerator
Circuit Maximum Fuse
/
Minimum Wire Size
3 amps
/
14AWG
CAUTION
DO NOT operate the refrigerator on 12
volt
DC when
the vehicle is parked. The amperage draw of the 12
volt DC heating element can discharge a battery in a
very short time. The installation of a 12 volt DC
operated refrigerator requires a relay to be installed
on the tow vehicle or in the caravan. The relay will
automatically shut off the 12 voit DC power to the
refrigerator when the ignition is turned off. (See FIG.
11).
FIG. 11
BREAKER
POINT
BATTERY
BATTERY
12.
CHANGING DOOR HINGES
FROM ONE SIDE TO THE
OTHER
(Refer to FIG. 12) Open the top door (or door on single
door models) and remove the two screws holding the top
decoration. The screws are accessible from beneath.
Remove the top hinge pin and lift out the lower
door. Remove center hinge pin (on two door models)
and lift out the lower door. Unscrew the bottom hinge
pin. Remove the plastic cap from the opposite lower
hinge and place it in the hole just left by
the lower hinge
pin. Screw the lower hinge pin in the hole from which the
plastic cap was removed.
Before replacing the door(s) on the refrigerator,
remove the catch(es) and move it (them) to the other
side of the cabinet. Plastic caps for the empty holes are
in the pans bag. Remount the door(s) and the hinge
pin(s) in the reverse order of their removal. Unscrew the
handle(s) and re-fasten it (them) on the opposite side of
the door. insert the plastic caps (from the pans bag) into
the holes left open on the door(s). Before the top
decoration is refitted, check that the door closes easily
and the gasket seals well on all sides.
FIG. 12
