3
SYMPTOM CAUSE
16. Ice Maker fails to start. Operation
Arm in Up Position
AC Voltage
Water Valve
Ice Maker Cycle
17. Ice Maker won’t make ice. Blades Frozen in Ice
AC Voltage
Water Valve
Ice Maker Cycle
18. Keeps making ice and won’t shut off. Shut-off arm
19. Not making enough ice. Operation
Mold Thermostat
Cube Size
Ice Maker Cycle
20. Too much water is coming out. Water Fill Adjustment
Water Valve
21. Ejector blade frozen into ice cubes. Water Fill Adjustment
Water Valve
22. Unit is hooked-up no water comes in. Water
Water Valve
23. Ice maker is running but won’t make cubes. Water
Shut-Off Arm
Mold Thermostat
Hold Switch
24. Ice maker will not make ice. Ice Ejector
Mold Heater
Timing Motor
ICE MAKER SECTION
