Dometic RMDX21 User Manual

RMDX21, RMDX25
15
Item Description
1Heating cartridge AC power
2AC power connection cable
3Earth AC power
4Ionisation
5Ignition
6Burner
7Heating cartridge DC power supply
8Heating cartridge DC power
9LED lighting
10 Electronics DC power supply
11 Gas inlet
12 Gas outlet
13 Gas valve
14 DC power outlet
15 Gas valve supply line
16 Switch-off fuse (overheating protection)
AOptional connections to DC power outlet
BNegative terminal (–) DC permanent supply for electronics
CPositive terminal (–) DC permanent supply for electronics
DConnection D+
EHeating element positive terminal (+) DC power
FHeating element earth terminal DC power
GConnection S+
br brown
rt red
sw black
ws white

Dometic RMDX21 Specifications

General

Type	Absorption
Climate Class	SN
Energy Source	12V, 230V, Gas
Input Voltage	12V DC, 230V AC
Refrigerant	Ammonia
