RMDX21, RMDX25
16
u
+-+-
House Battery
Anderson Plug
Anderson cables must be the
recommended size.
AES
Refrigerator DC connections
D+ Control Element DC
DC B E F
v
+-+-
Vehicle Anderson plug must
be controlled by ignition relay.
House Battery
Anderson Plug
Anderson cables must be the
recommended size.
AES
Refrigerator DC connections
D+ Control Element DC
DC B E F
w
