RUA5208X, RUA6408X, RUA8408X Installing the refrigerator
21
➤ Install the mounting plate (fig. l).
➤ Fill the opening with fire-resistant material (e.g. stone wool (fig. l).
I
➤ Slide the flue pipe at least 15 mm on the T-piece (fig. l).
➤ Attach the cover for the flue stack outside on the vehicle (fig. m).
6.8 Securing the refrigerator
!
I
➤ Push the refrigerator firmly into its final location with the front flange sitting hard
against the recess front.
NOTE
In some installation situations, it is possible that the flue pipe would
extend too far out of the vehicle in its installed state. Shorten the flue
pipe to the correct length if necessary.
CAUTION!
Only screw through the bushes built into the refrigerator, otherwise
foamed components, including electrical wiring, can be damaged.
NOTE
Ensure that the screws are tight, even when under increased loads
(while driving).
