Using the refrigerator RUA5208X, RUA6408X, RUA8408X
32
I
➤ Position the refrigerator door on the hinge pin of the newly mounted lower
hinge (1. in fig. n).
➤ Put the top pin in place (fig. n 1).
➤ Fix the top of the refrigerator door by pushing the top pin into the refrigerator
door top bush.
➤ Fit the top pin cover (fig. n 2).
✔ The refrigerator door is now fixed.
NOTE
Push and keep the latch spring bolt fully in during fitting.
