RUA5208X, RUA6408X, RUA8408X Using the refrigerator
33
7.13 Reversing the doors for RUA6408X, RUA8408X
➤ Open the freezer door more than 90 degrees.
➤ Remove the three screws (fig. o 1) from the upper hinge.
➤ Pull the upper hinge upwards out of the bushing and away from the freezer door
(2. in fig. o).
➤ Remove the freezer door by lifting it up until it clears the centre hinge pin (3. in
fig. o).
I
➤ Place the freezer door on soft material in order to prevent scratches.
➤ Support the refrigerator door so that it does not fall off.
➤ Pull out the centre hinge pin (4. in fig. o).
NOTE
Carefully lift up the freezer door to prevent damaging the door bushing.
≥90°
o
1.
2.
1
3.
4.
