Using the refrigerator RUA5208X, RUA6408X, RUA8408X
34
➤ Remove the refrigerator door by lifting it up until it clears the lower pin (1. in
fig. p).
I
➤ Place the refrigerator door on soft material in order to prevent scratches.
➤ Remove the three screws from the lower hinge (2. in fig. p).
➤ Rotate the locking catches on the latch side by 180 degrees to expose the fixing
screws.
NOTE
Carefully lift up the refrigerator door to prevent damaging the door
bushing.
1.
