Using the refrigerator RUA5208X, RUA6408X, RUA8408X
36
I
➤ Remove the two screws (1. in fig. s ) from the latch assembly on both doors.
➤ Push the spring bolt (2. in fig. s) inwards with a small screwdriver, until the latch
assembly (fig. s 1) is released.
➤ Remove the latch assembly (3. in fig. s) from both doors.
➤ Remove the latch blanks from the opposite side of both doors.
➤ The original freezer and refrigerator door latch assemblies swap to the opposite
door due to the spring bolt function.
➤ Relocate the door hinge bush to the opposite side.
➤ Exchange the latch assemblies and latch blanks and install each of them
on the opposite side.
NOTE
When installing the latch assemblies, push and keep the latch spring
bolt fully in.
3.
