RUC5(x)08X, RUC6(x)08X, RUC8(x)08X Installation
23
1. Apply the sealing strip to all four sides of the bottom surface of the refrigerator (fig. h 1).
2. Push the refrigerator into position (fig. h 2).
✔ The space behind the refrigerator is sealed to the interior of the vehicle.
7.7 Securing the refrigerator
!
1. Slide the refrigerator into its final place.
2. Align the refrigerator so that
– The front flange is flush with the front edge of the recess.
– The refrigerator is standing level.
3. Insert the screws (fig. i 1) through the plastic bushings on the sides of the refrigerator and screw the refriger-
ator into the recess.
4. Fit the caps (fig. i 2) onto the bushings.
CAUTION! Electrocution hazard and damage hazard
• Only screw through the holes provided on the refrigerator for fastening to prevent injury from
damaged electrical cables or damage to foamed components.
• Ensure to tighten the screws firmly so that they do not loosen under increased load (e.g., while
driving).
