RUC5208X, RUC6408X, RUC8408X Using the refrigerator
45
➤ Use the latch assembly from the door reversing kit (not included, see chapter
“Accessories” on page 7).
➤ Fit the new latch assembly and the original latch blank to the opposite side.
➤ Position the refrigerator door on the hinge pin of the newly mounted lower
hinge (1. in fig. F).
➤ Put the top pin in place (2. in fig. F).
➤ Fix the top of the refrigerator door by pushing the top pin into the refrigerator
door top bush.
✓ The refrigerator door is now fixed.
