Dometic S7 - Page 5

first two clamps on the right and left side at the bottom. In cases where the frame is not aligned with an
equal contact surface all around it is necessary to use more clamps as shown in the table.
Approx. Need of Clamps
Window Size
Width x Height
approx.
Quantity
horizontally
(each side)
approx.
Quantity
vertically
(each side)
approx.
Total quantity
(each window)
300 x 450 2 4/3 11
450 x 510 4 3 14
500 x 300 4 2 12
500 x 400 4 3 14
510 x 510 4 3 14
550 x 600 4 4 16
600 x 250 4 2 12
600 x 510 4 3 14
600 x 550 4 4 16
650 x 300 4 2 12
650 x 400 4 3 14
700 x 350 6 2 16
700 x 500 6 3 18
800 x 400 6 3 18
800 x 510 6 3 18
900 x 450 6 3 18
900 x 500 6 3 18
900 x 600 6 4 20
1000 x 300 6 2 16
1000 x 450 6 3 18
1000 x 510 6 3 18
1000 x 600 6 4 20
1100 x 350 6 2 16
1100 x 600 6 4 20
1200 x 300 6 2 20
1200 x 450 8 3 22
1300 x 510 8 3 22
1300 x 600 8 4 24
1300 x 700 8 6 28
1400 x 600 8 4 24
1450 x 550 8 4 24
