Dometic SeaStar - Remote Fill Connection Installation

11
10
11
10
This kit will provide means to ll and vent the steering system above
the dash or console. A 7/8" hole will need to be drilled into the dash/
console ABOVE the helm pump, prior to drilling any holes, conrm that
you will not drill into any functioning equipment.
1. Locate desired location for placement of the helm ll plug onto of
the dash/console. Look beneath the dash/console to conrm that
there is sufcient space for the ll hose and ttings. Conrm that
there is no interference with any other equipment. Mark the location
and drill a 7/8" hole from above or below the dash/console.
2.
Apply a liquid, Teon based pipe sealant to the threads of the elbow
tting going into the helm pump, DO NOT use Teon Tape, ONLY use
the paste type pipe sealant. Screw the brass elbow barb tting
into the helm ll port. DO NOT install the plastic elbow tting into
the helm.
Remote Fill & Vent
3. Attach the vinyl tubing to the elbow tting that you just installed into
the helm pump and secure with a hose clamp. A small amount of
oil inside the vinyl tube will help slide it onto the elbow barb tting.
4. Insert ll tting from the top of the dash/console and secure with
the jam nut.
A spacer may be required if mounting surface is less than 3/8"
thick, this spacer is provided in this kit
5.
Apply a liquid, Teon based pipe sealant to the threads of the plastic
elbow tting that will be installed into the ll tting. DO NOT use
Teon Tape; ONLY use the paste type pipe sealant.
6. Vinyl hose MUST have a gradual rise from the helm tting to the
ll tting to allow air to rise. Cut vinyl tube to the required length
and secure to the ll tting with a hose clamp.
TIP: Measure twice; cut once.
ELBOW HOSE BARB
FITTING
FILL FITTING
VENT PLUG
HELM PUMP
Figure 7.
Remote Fill Connection Installation
NOTICE
Sport Tilt Shown, Sport Plus similar.
CAUTION
DO NOT attempt to install NPT
pipe ttings into a cylinder and/
or helm pump tted with ORB
hose tting port. Doing so will
lead to irreparable damage to the
cylinder and/or helm port. ONLY
use SeaStar ORB hose ttings
provided by Dometic.
DO NOT use steel NPT ttings
with SeaStar Helm Pumps, use
brass NPT ttings ONLY.
NPT tting installations ONLY:
• Apply a liquid, Teon based pipe
sealant onto the threads going
into the pump
• Tighten tting HAND-TIGHT
• using a wrench, tighten an
additional 1.5 turns
• continue to tighten until
desired orientation is met
